Omada 2000W Model: A2-1
Omada 200W A2-1 is a high-capacity, versatile power station designed for a range of applications including off-grid power supply, emergency backup, and renewable energy systems. With a total capacity of 720,000mAh (720Ah) at 3.2V, this power station is capable of providing significant energy to multiple devices, ensuring that your equipment stays powered up in various situations.
Key Features
Battery Capacity & Type:
Total Capacity: 720,000mAh (720Ah) at 3.2V, delivering up to 2304Wh of energy.
Cell Type: The power station uses Lithium Iron Phosphate (LiFePO4) cells in a 33140 cylindrical type, known for their longevity, safety, and stable performance.
DC Input & MPPT (Maximum Power Point Tracking):
DC5521 Input: Accepts input from 10-45V at up to 10A, supporting photovoltaic MPPT tracking, making it compatible with solar panels to harness renewable energy efficiently.
XT60 Input: Accepts input from 10-45V, supporting up to 400W input with MPPT tracking for photovoltaic applications.
AC Input:
Pin Zi AC Input Interface: Accepts 180-250V, rated power of 1000W, providing versatility for charging from traditional AC power sources.
AC Output:
AC Cocket Interface: Provides AC220V±5% through two interfaces, capable of powering a wide range of AC devices and appliances.
USB & Type-C Outputs:
TYPE-C1 (QC3.0): Supports 12V/1.5A (18W) for fast charging and PD (Power Delivery) Max 12V/2.5A (30W) for higher efficiency charging.
TYPE-C2 (PD/QC3.0): Provides 20V/5A (100W) for high-power devices, supporting fast charging.
USB-A1 (QC3.0): Delivers up to 20V/3A (60W) for rapid charging of compatible devices.
USB-A2 (QC3.0): Supports 12V/1.5A (18W) for smaller devices.
Wireless Charging:
Wireless Charging Pad: Offers up to 15W Max for devices that support Qi wireless charging.
DC & Other Outputs:
DC1, DC2 (Cigarette Lighter): Provides 12V/10A (120W) for car-powered devices.
LED Light: Equipped with a high-brightness LED light (4-8W) with secondary dimming and SOS flashing for emergency situations.
